MEAN WELL DCWN06 Series: Regulated Voltage Converter - DCWN06B-05

Description

Series: Double group output Rated power: 6W Input voltage (range): standard voltage 24V(18~36V) Input current no-load: 8mA, full load: 254mA Output voltage: ± 5V Output current: ± 0 ~ 500mA Efficiency (TYP.):82% Capacitive load (max):* 2200μF Size (mm):31.8X20.3X10.2

Click to download Airtac product catalog

Product Features

1. DIP24 package, industry standard pin.

2, 2:1 wide input range, working temperature range -40~90 ℃, no minimum load.

3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 87%.

4. Protection: short circuit (continuous)/overload/input undervoltage, 3KVDC input/output isolation, 3 years warranty.

MEAN WELL DCWN06 Series: Regulated Voltage Converter - DCWN06B-05

Product form

Series: Double group output Rated power: 6W Input voltage (range): standard voltage 24V(18~36V) Input current no-load: 8mA, full load: 254mA... Read more

$20.57 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Double group output Rated power: 6W Input voltage (range): standard voltage 24V(18~36V) Input current no-load: 8mA, full load: 254mA Output voltage: ± 5V Output current: ± 0 ~ 500mA Efficiency (TYP.):82% Capacitive load (max):* 2200μF Size (mm):31.8X20.3X10.2

    Click to download Airtac product catalog

    Product Features

    1. DIP24 package, industry standard pin.

    2, 2:1 wide input range, working temperature range -40~90 ℃, no minimum load.

    3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 87%.

    4. Protection: short circuit (continuous)/overload/input undervoltage, 3KVDC input/output isolation, 3 years warranty.
