Description
Output voltage: 48V Output current: 0 ~ 5A Output power rating: 240W Output peak current: 7.5A Output peak power: 360W(3sec.) Continuous input voltage range: 33.6 ~ 67.2VDC Input voltage range 100ms:28.8~33.6VDC Size (mm):40X125.2X113.5
Product Features
1. Metal shell, 2:1 wide range input.
2. Railway & ITE dual certification, 150% peak load.
3, -40 ~ +70 ℃ wide range of working temperature, no fan design, natural air cooling.
4. Mounting guide rail: TS-35/7.5 or TS-35/15.
5, 4KVdc I/O enhanced isolation, DC output adjustable (± 15%).
6. DC OK relay control and remote control ON/OFF(DDR-240/480).
7. Current sharing and parallel connection function, up to 4 units can be connected in parallel (DDR-240 W/480, up to 960W/1920W).
8. Protection type: short circuit/overload/overvoltage/input undervoltage/input reverse polarity protection, 3 years warranty.
