MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01N-05N

Description

New series Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):74% Capacitive load (max):± 470μF Size (mm):15.24X10.9X7.1

Click to download Airtac product catalog

Product Features

1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%.

2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.

MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01N-05N

Product form

New series Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 5V... Read more

$14.14 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    New series Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):74% Capacitive load (max):± 470μF Size (mm):15.24X10.9X7.1

    Click to download Airtac product catalog

    Product Features

    1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%.

    2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
