MEAN WELL DETN02-N series: DC-DC unregulated converter - DETN02L-12N

Description

New series Rated power: 2W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 60mA, full load: 500mA Output voltage: ± 12V Output current: ± 8 ~ 83mA Efficiency (TYP.):81% Capacitive load (max):± 220μF Size (mm):15.24X10.9X9.1

Click to download Airtac product catalog

Product Features

1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +85 ℃, and the efficiency is as high as 83%.

2.3KVDC input/output isolation, low cost, 3 years warranty.

MEAN WELL DETN02-N series: DC-DC unregulated converter - DETN02L-12N

Product form

New series Rated power: 2W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 60mA, full load: 500mA Output voltage: ± 12V... Read more

$15.00 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    New series Rated power: 2W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 60mA, full load: 500mA Output voltage: ± 12V Output current: ± 8 ~ 83mA Efficiency (TYP.):81% Capacitive load (max):± 220μF Size (mm):15.24X10.9X9.1

    Click to download Airtac product catalog

    Product Features

    1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +85 ℃, and the efficiency is as high as 83%.

    2.3KVDC input/output isolation, low cost, 3 years warranty.
