MEAN WELL DETN02 Series: DC-DC Unregulated Converter - DETN02M-05SC

Description

Rated power: 2W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 30mA, full load: 208mA Output voltage: ± 5V Output current: ± 20 ~ 200mA Efficiency (TYP.):80% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1

Click to download Airtac product catalog

Product Features

1. SMD package has industry standard pins, operating temperature range -40 ~ +100 ℃, conforming to BS EN/EN55032 radiation Class A, no additional components, and efficiency as high as 83%.

2. Protection: short circuit, 3KVDC input/output isolation, low cost, optional reel packaging, 3 years warranty.

MEAN WELL DETN02 Series: DC-DC Unregulated Converter - DETN02M-05SC

Product form

Rated power: 2W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 30mA, full load: 208mA Output voltage: ± 5V Output current:... Read more

$15.00 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Rated power: 2W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 30mA, full load: 208mA Output voltage: ± 5V Output current: ± 20 ~ 200mA Efficiency (TYP.):80% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1

    Click to download Airtac product catalog

    Product Features

    1. SMD package has industry standard pins, operating temperature range -40 ~ +100 ℃, conforming to BS EN/EN55032 radiation Class A, no additional components, and efficiency as high as 83%.

    2. Protection: short circuit, 3KVDC input/output isolation, low cost, optional reel packaging, 3 years warranty.
