Description
Series: Double group output Rated power: 10W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 473mA Output voltage: ± 15V Output current: ± 0 ~ 333mA Efficiency (TYP.):86% Capacitive load (max):* 100μF Size (mm):50.8X25.4X11.2
Click to download Airtac product catalog
Product Features
1. The DIP2 "x1" package has industry standard pins.
2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required.
3. Comply with BS EN/EN55032 Radiation Class A, no additional parts are required, and the efficiency is as high as 88%.
4. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, 3KVdc input/output isolation, remote on/off control (optional),3 years warranty
