MEAN WELL DKM10W8 series: voltage regulator converter - DKM10W8-12

Description

Series: Double group output Rated power: 10W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 244mA Output voltage: ± 12V Output current: ± 0 ~ 417mA Efficiency (TYP.):85% Capacitive load (max):* 417μF Size (mm):25.4X25.4X10.2

Click to download Airtac product catalog

Product Features

1. The DIP 1 "X1" package has industry standard pins.

2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load requirement, efficiency as high as 85%.

3. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, 3KVdc input/output isolation.

4. Remote on/off control, adjustable output range (± 10%),3-year warranty.

MEAN WELL DKM10W8 series: voltage regulator converter - DKM10W8-12

Product form

Series: Double group output Rated power: 10W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 244mA Output voltage:... Read more

$36.86 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Double group output Rated power: 10W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 244mA Output voltage: ± 12V Output current: ± 0 ~ 417mA Efficiency (TYP.):85% Capacitive load (max):* 417μF Size (mm):25.4X25.4X10.2

    Click to download Airtac product catalog

    Product Features

    1. The DIP 1 "X1" package has industry standard pins.

    2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load requirement, efficiency as high as 85%.

    3. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, 3KVdc input/output isolation.

    4. Remote on/off control, adjustable output range (± 10%),3-year warranty.
