MEAN WELL DKM30-N series: Isolated dual-output DC-DC converter - DKM30F-15N

Description

DKM30F-15N — Isolated dual-output DC-DC converter

MEAN WELL DKM30F-15N is an isolated, regulated dual-output DC-DC converter accepting 9–36 V DC. It provides ±15 V DC relative to COM with 1000 mA per rail. It uses the standard 2 × 1 inch pin package. Remote ON/OFF is provided and no minimum load is required.

Download MEAN WELL DKM30-N Datasheet (PDF)

Series section: PDF pages 43–51.

Model and output specifications

Output voltage ±15 V DC relative to COM.
Rated output current 1000 mA per output rail.
Series power and load limit 30 W. Observe the current and total output-power limits together.
Minimum load No minimum load is required.
Voltage accuracy ±2.0% maximum
Line regulation ±0.2%; low-to-high input at rated load.
Load regulation ±0.5%, measured over 0–100% load.
Ripple and noise 150 mVp-p maximum. Measured at 20 MHz bandwidth with a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors.
Switching frequency 380 kHz typical.
Maximum capacitive load 100 µF for each output.

Input, control and protection

Input voltage 9–36 V DC; 4:1 range. Nominal inputs 12 and 24 V.
Input current 38 mA at no load; 2800 mA at full load, at 12 V input.
Typical efficiency 88% at the reference conditions.
Input filter and fuse Pi filter. The manufacturer recommends a 6 A slow-blow external fuse; select it for the actual input and installation.
Overload protection 110–230%; automatic recovery after the fault is removed.
Short-circuit protection Continuous protection with automatic recovery.
Input overvoltage protection Input shutdown at 40 V DC typical.
Output overvoltage protection Clamped by TVS.
Remote ON/OFF Referenced to −Vin: >2.5–5 V or open circuit turns the output ON; <1 V or a short circuit turns it OFF.
Configuration This model uses the standard pin type; ST is the separately identified screw-terminal configuration.
Other output options A 24 V single-output option is mentioned in the catalog; obtain its complete order code and specifications from the manufacturer.

Operating conditions and isolation

Operating temperature and cooling −40 to +90°C; free-air convection. Apply the load-derating limits.
Load derating Full load through 60°C; 50% at 80°C; 25% at 90°C.
Maximum case temperature 110°C.
Working humidity 5–95% RH, non-condensing.
Storage conditions −55 to +125°C; 10–95% RH, non-condensing.
Temperature coefficient ±0.05%/°C.
Vibration 10–500 Hz, 2G; 10 minutes per cycle for 60 minutes along each of the X, Y and Z axes.
Reference test conditions 12 V DC input, rated load, 25°C and 70% RH, unless otherwise stated.
Input-to-output withstand voltage 3 kV DC.
Isolation resistance 100 MΩ.
Isolation capacitance 1000 pF typical.

Mechanical design and installation

Dimensions 50.8 × 25.4 × 11.2 mm (L × W × H).
Case construction Metal case with shielding on all six sides.
Pin assignment 1 +Vin; 2 −Vin; 3 Remote ON/OFF; 4 +Vout; 5 COM; 6 −Vout. Check the bottom-view orientation before PCB assembly.
Mechanical drawing details Pin diameter 1 ±0.1 mm; lead length 5.8 mm. Use the bottom-view drawing for PCB placement.
Unit weight reference 31 g, explicitly stated as a catalog packing reference per unit.
Soldering 3–5 seconds at 265°C maximum, measured 1.5 mm from the case.

EMC and manufacturer references

Safety and catalog references EAC TP TC 020/2011 approved.
EMC emission BS EN/EN 55032 radiated Class A without additional components. Conducted emission is listed as N/A in the specification; Class B uses the external reference circuit.
EMC immunity BS EN/EN 61000-4-2: 4 kV contact, Level 2; -4-3: 3 V/m, Level 2; -4-4: 0.5 kV, Level 1; -4-5: 0.5 kV line-to-line, Level 2; -4-6: 3 V emf, Level 2.
MTBF reference >250 khrs to MIL-HDBK-217F at 25°C; a reliability reference, not a service-life guarantee.
Manufacturer warranty reference The catalog states a 3-year manufacturer warranty.
Class B EMC example F1: 6 A slow-blow fuse; C1: 47 µF/100 V; C2: 3.3 µF/50 V, MLCC 1210; C3/C4: 1000 pF/5 kV MLCC; L1: 325 µH common-mode choke. Use the complete circuit and verify the final equipment.
