Description
Series: Double group output Rated power: 30W Input voltage (range):Nominal 24V,48V(18~75V) Input current no-load: 25mA, full load: 1400mA Output voltage: ± 15V Output current: ± 0 ~ 1000mA Efficiency (TYP.):89% Capacitive load (max):* 100μF New series Screw terminal type (optional) Size (mm):50.8X25.4X11.2
Click to download Airtac product catalog
Product Features
1. The DIP2 "x1" package has industry standard pins.
2.4:1 ultra-wide input range, operating temperature range -40 ~ +90 ℃(-40 ~ +60 ℃ without reduction), no minimum load.
3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 89%.
4. Protection: short circuit (continuous)/overload/overvoltage, 3KVDC input/output isolation, remote control on/off, fine adjustment output (± 10%).
5. Provide screw terminal type (optional), provide 24Vo model (only single output optional),3 years warranty.
