Description
Series: Double group output Rated power: 40W Input voltage (range):Nominal 24V(9~36V) Input current no-load: 12mA, full load: 1870mA Output voltage: ± 15V Output current: ± 0 ~ 1333mA Efficiency (TYP.):88% Capacitive load (max):* 1000μF Size (mm):25.4X25.4X10
Click to download Airtac product catalog
Product Features
1. The DIP 1 "X1" package has industry standard pins.
2.4:1 ultra-wide input range, operating temperature range -40~80 ℃, no minimum load required.
3. Comply with BS EN/EN55032A/B standard, and equipped with additional components, the efficiency is as high as 91%.
4. Protection: short circuit (continuous)/overload/overvoltage/over temperature/input undervoltage, 2KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
