MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02B-12

Description

Series: Double group output Rated power: 2W Input voltage (range):24V(18~36V) Input current no-load: 19mA, full load: 102mA Output voltage: ± 12V Output current: ± 0 ~ 83mA Efficiency (TYP.):81% Capacitive load (max):* 83μF Size (mm):21.8X9.2X11.1

Click to download Airtac product catalog

Product Features

1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required.

2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%.

3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.

MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02B-12

Product form

Series: Double group output Rated power: 2W Input voltage (range):24V(18~36V) Input current no-load: 19mA, full load: 102mA Output voltage: ±... Read more

$20.02 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Double group output Rated power: 2W Input voltage (range):24V(18~36V) Input current no-load: 19mA, full load: 102mA Output voltage: ± 12V Output current: ± 0 ~ 83mA Efficiency (TYP.):81% Capacitive load (max):* 83μF Size (mm):21.8X9.2X11.1

    Click to download Airtac product catalog

    Product Features

    1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required.

    2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%.

    3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
