MEAN WELL DPRN01 Series: DC-DC Regulated Converter - DPRN01M-15

Description

Series: Double group output Rated power: 1W Input voltage (range):Normal 12V(11.4~13.2V) Input current no-load: 18mA, full load: 120mA Output voltage: ± 15V Output current: ± 0 ~ 34mA Efficiency (TYP.):69% Capacitive load (max):* ± 47μF Size (mm):19.6X7.1X10.14

Click to download Airtac product catalog

Product Features

1. SIP6 package has industry standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation level B, no additional components are required.

2. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, cheap price, 3 years warranty.

MEAN WELL DPRN01 Series: DC-DC Regulated Converter - DPRN01M-15

Product form

Series: Double group output Rated power: 1W Input voltage (range):Normal 12V(11.4~13.2V) Input current no-load: 18mA, full load: 120mA Output voltage:... Read more

$13.29 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Double group output Rated power: 1W Input voltage (range):Normal 12V(11.4~13.2V) Input current no-load: 18mA, full load: 120mA Output voltage: ± 15V Output current: ± 0 ~ 34mA Efficiency (TYP.):69% Capacitive load (max):* ± 47μF Size (mm):19.6X7.1X10.14

    Click to download Airtac product catalog

    Product Features

    1. SIP6 package has industry standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation level B, no additional components are required.

    2. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, cheap price, 3 years warranty.
