MEAN WELL DPU01 Series: DC-DC Unregulated Converter - DPU01M-15

Description

Series: Double group output Rated power: 1W Input voltage (range):12V(10.8~13 .. 2V) Input current no-load: 15mA, full load: 108mA Output voltage: ± 15V Output current: ± 0 ~ 33mA Efficiency (TYP.):78% Capacitive load (max):* 100μF Size (mm):19.5X6.1X10.2

Click to download Airtac product catalog

Product Features

1. SIP6 package has industry standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class A, no additional components.

2. Protection type: short circuit, 1.5KVDC input/output isolation, low cost, 3 years warranty.

MEAN WELL DPU01 Series: DC-DC Unregulated Converter - DPU01M-15

Product form

Series: Double group output Rated power: 1W Input voltage (range):12V(10.8~13 .. 2V) Input current no-load: 15mA, full load: 108mA Output... Read more

$6.86 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Double group output Rated power: 1W Input voltage (range):12V(10.8~13 .. 2V) Input current no-load: 15mA, full load: 108mA Output voltage: ± 15V Output current: ± 0 ~ 33mA Efficiency (TYP.):78% Capacitive load (max):* 100μF Size (mm):19.5X6.1X10.2

    Click to download Airtac product catalog

    Product Features

    1. SIP6 package has industry standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class A, no additional components.

    2. Protection type: short circuit, 1.5KVDC input/output isolation, low cost, 3 years warranty.
