MEAN WELL DRDN-20 Series: Rail-type redundant modules - DRDN20-48

Description

Rail-type redundant module Number of inputs: 2 channels Input DC voltage rating: 48Vdc Input rated voltage range: 36 ~ 60Vdc Input rated current: each input 0 ~ 20A continuous Output rated current: 0 ~ 20A, continuous Size (mm):32X125.2X102

Product Features

1. Supports 1+1 and N +1 redundant systems.

2. Mounting guide rail: TS-35/7.5 or TS-35/15.

3. Output current 20A & 40A.

4. Suitable for 12V/24V/48 redundant system.

5. Two input and one output channel.

6, -40 ~ +80 ℃ ultra wide working temperature (>+60 ℃ reduction).

7. Built-in two-channel DC OK signal and alarm relay contact.

8. LED power start indicator, 3 years warranty.

MEAN WELL DRDN-20 Series: Rail-type redundant modules - DRDN20-48

Product form

Rail-type redundant module Number of inputs: 2 channels Input DC voltage rating: 48Vdc Input rated voltage range: 36 ~ 60Vdc... Read more

$50.14 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Rail-type redundant module Number of inputs: 2 channels Input DC voltage rating: 48Vdc Input rated voltage range: 36 ~ 60Vdc Input rated current: each input 0 ~ 20A continuous Output rated current: 0 ~ 20A, continuous Size (mm):32X125.2X102

    Product Features

    1. Supports 1+1 and N +1 redundant systems.

    2. Mounting guide rail: TS-35/7.5 or TS-35/15.

    3. Output current 20A & 40A.

    4. Suitable for 12V/24V/48 redundant system.

    5. Two input and one output channel.

    6, -40 ~ +80 ℃ ultra wide working temperature (>+60 ℃ reduction).

    7. Built-in two-channel DC OK signal and alarm relay contact.

    8. LED power start indicator, 3 years warranty.
