Description
Output voltage: 36V Output current: 0 ~ 6.6A Total output power: The total power of all channels shall not exceed 240W, load priority. Peak power 275W in 5 seconds Input voltage: 90 ~ 305VAC,127 ~ 431VDC Size (mm):85.5X125.2X129.2 Function: Built-in MODBus
Product Features
1. International universal full range input: 90 ~ 305VAC.
2. Multi-functional integrated intelligent safety control fire power supply (integrating power supply, DC UPS, battery charging and status monitoring).
3. The design meets the requirements of UL2524/EN54-4/GB17945 signal alarm regulations. When the AC power grid is abnormal, the load will give priority to power supply to avoid equipment shutdown.
4. Form-C relay is adopted to detect AC Fail, DC OK, low battery voltage warning and abnormal detection of charging circuit.
5. Built-in MODBus communication (optional CANBus).
6. Protection type: short circuit/overload/overvoltage/overtemperature (automatic load reduction)/battery cut off/battery low voltage/battery reverse connection (will not be damaged).
7.20~100 charging current is adjustable through VR, and 2 or 3 charging curves can be adjusted through DIP S.W.
8, -30 ~ +70 ℃ wide temperature work, suitable for lead acid or lithium battery, 3 years warranty.
