Description
Output current rating: 700mA Output constant current range: 142~286V Output open circuit voltage (maximum):300V Input voltage: 100 ~ 305VAC,142 ~ 431VDC IP rating: IP67 Function: equipped with intelligent timing dimming and adjustment function, standard products Input line type: 2-line input (standard) Size (mm):244X71X37.5
Product Features
1. Constant voltage + constant current output mode (ELG series).
2. Constant current output mode (ELG-C series).
3. Constant power mode output (ELGC-300 series).
4. Wide range input: 100 ~ 305VAC, the highest efficiency can reach 94%.
5. Metal shell grounding design, surge immunity up to 6KV(IEC61000-4-5).
6. Explosion-proof HL type LED driver, can be used for Class I,Division 2 lighting equipment in hazardous places.
7. Built-in active PFC, no-load/standby consumption <0.5W, optional protection function: current and voltage adjustment, multiple dimming functions.
8. Protection type: short circuit/overvoltage/overcurrent/overtemperature; 5 years warranty.
