Description
4 "X2" Small Form Factor chassis type Output voltage: 3.3V Rated output current: 11A Output current range: 0 ~ 12A Rated power: 36.3W Peak load (10 seconds):39.6W Input voltage: 90 ~ 264VAC,127 ~ 370VDC [DC input operation can be realized by connecting AC/N(+),AC/L(-)] Size (mm):103.4X62X37
Product Features
1. International universal full range input.
2, no-load power consumption <0.1~0.3W,110 peak power up to 10 seconds.
3. Small size, 1U low height, natural air cooling heat dissipation.
4. Protection type: short circuit/overload/overvoltage.
5, Class I or Class II device,-30 ~ +70 ℃ wide temperature operation.
6. Built-in 12V@0.5A fan auxiliary power supply (EPS-120).
7. LED power start indicator (EPS-15), and shell model (EPS-45/65-C).
8, 3 years warranty.
