MEAN WELL GD2 Series: Gate Driver Power DC-DC Converter - GD2-121509

Description

Rated power: 2W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 43mA, full load: 217mA Output voltage: +15V/-9V Output current: +10 ~ 100mA/-6 ~ 60mA Efficiency (TYP.):82% Capacitive load (MAX.):100μF Size (mm):19.5X9.8X12.5

Click to download Airtac product catalog

Product Features

1. The SIP7 package conforms to the international standard pin, and the working temperature range is ~ 40 ~ +90 ℃.

2. Performance optimization for IGBT/SiC, bipolar asymmetric unregulated output, low coupling isolation capacitance (Cio).

3. Protection function: short circuit protection (continuous),6.2KVDC or 4.2KVAC high input/output isolation, low cost, 3 years warranty.

MEAN WELL GD2 Series: Gate Driver Power DC-DC Converter - GD2-121509

Product form

Rated power: 2W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 43mA, full load: 217mA Output voltage: +15V/-9V Output current: +10... Read more

$20.14 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Rated power: 2W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 43mA, full load: 217mA Output voltage: +15V/-9V Output current: +10 ~ 100mA/-6 ~ 60mA Efficiency (TYP.):82% Capacitive load (MAX.):100μF Size (mm):19.5X9.8X12.5

    Click to download Airtac product catalog

    Product Features

    1. The SIP7 package conforms to the international standard pin, and the working temperature range is ~ 40 ~ +90 ℃.

    2. Performance optimization for IGBT/SiC, bipolar asymmetric unregulated output, low coupling isolation capacitance (Cio).

    3. Protection function: short circuit protection (continuous),6.2KVDC or 4.2KVAC high input/output isolation, low cost, 3 years warranty.
