Description
Rated output current: 2.7A Output power rating: 97.2W Output constant current range: 21.6~36V Output open circuit voltage (maximum):37V Input voltage: 90 ~ 305VAC,127 ~ 431VDC IP rating: IP65 Function: The current output value can be adjusted by the internal potentiometer & three-in-one dimming function, standard product Size (mm):ø130X66.5
Product Features
1. Constant current mode output (HBG-60/100).
2. Constant voltage + constant current mode output (HBG-160/200/240).
3. Constant power mode output (HBGC-300).
4, 60~100% current range can be with full load (HBGC-300).
5. Wide range input: 90 ~ 305VAC, metal round shape, Class I design (except HBG-60).
6. Built-in active PFC function, a variety of functions can be selected: output internal potentiometer adjustment, three-in-one, DALI dimming.
7. Protection type: short circuit/overcurrent (except HBG-60 and HBGC-300)/overvoltage (except HBG-60)/overtemperature.
8 and 5 years warranty.
