Description
Electrical specifications (optional features) Output average charging voltage Vboost:28.8V Output float voltage Vfloat:27.6V Output current: 0 ~ 35A Input voltage: 90 ~ 305VAC,250 ~ 431VDC Size (mm):310X144X48.5 Input and output type: terminal block type Function: CANBus and PV/PC communication protocol, optional
Product Features
1. International universal full range input: 90 ~ 305VAC.
2. Active PFC, with an efficiency of up to 96%, aluminum shell without fan design, filled with thermal conductive glue, conducts natural convection heat dissipation.
3. It can withstand 10G vibration test,-40 ~ +70 ℃ wide working temperature, with charging function for lead-acid battery and lithium ion battery.
4. Built-in CANBus;PMBus/Modbus (HEP-2300 only) optional, output voltage and current programmable.
5. Remote ON/OFF control (except HEP-1000 wiring type),DC OK signal and auxiliary power output.
6. HEP-2300 connector type with AC-fail fault and T-Alarm signal function.
7. Protection type: short circuit/overload/overvoltage/over temperature, IP67 only output line type.
8. LED power start indicator (except HEP-1000 wiring type),6-year warranty.
