Description
Terminal block lock line type Output DC voltage: 48V Peak output current (10 seconds):2.07A Output current natural air cooling: 1.88A Peak output power rating (10 seconds):99.2W Output rated power natural air cooling: 90.2W Input voltage: 80 ~ 305VAC,113 ~ 431VDC Size (mm):109X52X33.5
Product Features
1. International universal full range input: 85 ~ 305vac.
2. Full protective plastic shell, no-load power consumption <0.075~0.3W, miniature size, high power density.
3. Protection type: short circuit/overload/overvoltage, natural air cooling and heat dissipation.
4. Class II isolation level, OVC III overvoltage level (IRM-30 ~ 90).
5. Meet BS EN/EN55032 Class B without additional components.
6. Glue filling, dustproof, moisture resistance, 5G shock resistance, the maximum working temperature can reach +85 ℃.
7. Through LRS (except IRM-45/60-5 and IRM-90).
8, carrier plate installation and terminal locking type (IRM-30 ~ 90ST),3 years warranty.
