Description
Output current value: 700mA(default) Output power rating: 25.2W Output DC voltage range: 6~36V Output open circuit voltage (maximum):41V Input voltage: 180 ~ 277VAC,254 ~ 392VDC Function: Three-in-one dimming (0 ~ 10VDC,PWM signal, resistance dimming) Size (mm):105X68X23
Product Features
1. Constant current mode output, current position can be adjusted by Dial switch.
2. A variety of dimming functions are available: three-in-one/DALI-2/KNX.
3. Class II power supply, without FG.
4. Support 10 power synchronization function.
5.12V/50mA auxiliary DC output is optional (LCM-40/60).
6. Suitable for DALI-2 DT6 and DT8(DT8: LCM-40TW only).
7. Protection type: short circuit/overvoltage/overtemperature.
8.3-year warranty (LCM-25/40/60);5-year warranty (LCM-40TW).
