Description
Output current value: 900mA Output power rating: 60.3W Output DC voltage range: 2~67V Output open circuit voltage (maximum):73V Input voltage: 180 ~ 295VAC,254 ~ 392VDC Built-in DALI interface and key dimming Function: DALI and press dimming, standby power consumption <0.5W, standard product Size (mm):123.5X81.5X23
Product Features
1. Constant current mode output, current position can be adjusted by Dial switch.
2. A variety of dimming functions are available: three-in-one/DALI-2/KNX.
3. Class II power supply, without FG.
4. Support 10 power synchronization function.
5.12V/50mA auxiliary DC output is optional (LCM-40/60).
6. Suitable for DALI-2 DT6 and DT8(DT8: LCM-40TW only).
7. Protection type: short circuit/overvoltage/overtemperature.
8.3-year warranty (LCM-25/40/60);5-year warranty (LCM-40TW).
