Description
Output voltage: 24V Output constant current range: 14.4~24V Rated output current: 3.75A Output power rating: 90W Function: constant current output, with three-in-one dimming function Input voltage: 90 ~ 305VAC,127 ~ 431VDC Size (mm):161X61X36
Product Features
1. Constant current mode + constant voltage mode output, D-Type: only constant current mode; built-in three-in-one dimming function (0 ~ 10VDC,PWM signal, resistance).
2. International common input range: 90 ~ 305VAC.
3. Built-in active PFC function.
4. Fully enclosed plastic shell, meet IP67 grade (LPF-16(D) optional).
5. Class II design, no FG.
6. Class 2 power supply.
7. Protection type: short circuit/over current/over voltage/over temperature.
8 and 5 years warranty.
