MEAN WELL MDS15 Series: DC-DC Medical Grade Converter - MDS15C-12

Description

Rated power: 15W Input voltage (range):Normal 48V(36~75V) Input current no-load: 5mA, full load: 350mA Output voltage: 12V Output current: 1250mA Efficiency (TYP.):87% Capacitive load: 1000μF Size (mm):50.8X25.4X12

Click to download Airtac product catalog

Product Features

1. DIP 2 "X1" package has international standard pins, 2:1 wide input range, low leakage current <5μA, and operating temperature range of -40 ~ +90 ℃.

2, through the IEC60601-1 medical safety certification (2xMOPP), no minimum load requirements, protection mode: short circuit (continuous)/overload/input voltage.

3. 4000VAC high input/output isolation (enhanced isolation),3 years warranty.

MEAN WELL MDS15 Series: DC-DC Medical Grade Converter - MDS15C-12

Product form

Rated power: 15W Input voltage (range):Normal 48V(36~75V) Input current no-load: 5mA, full load: 350mA Output voltage: 12V Output current: 1250mA... Read more

$75.43 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Rated power: 15W Input voltage (range):Normal 48V(36~75V) Input current no-load: 5mA, full load: 350mA Output voltage: 12V Output current: 1250mA Efficiency (TYP.):87% Capacitive load: 1000μF Size (mm):50.8X25.4X12

    Click to download Airtac product catalog

    Product Features

    1. DIP 2 "X1" package has international standard pins, 2:1 wide input range, low leakage current <5μA, and operating temperature range of -40 ~ +90 ℃.

    2, through the IEC60601-1 medical safety certification (2xMOPP), no minimum load requirements, protection mode: short circuit (continuous)/overload/input voltage.

    3. 4000VAC high input/output isolation (enhanced isolation),3 years warranty.
