Description
Rated power: 21.6W Input voltage: 80 ~ 264VAC,113V ~ 370VDC Output voltage: 24V Output current: 0.9A Output peak current: 0.99A Output peak load (10 seconds):23.8W Size (mm):49X23.8X23
Product Features
1. International universal full range input: 80 ~ 264VAC.
2, bare plate price is low, medical safety certification (2xMOPP), suitable for BF grade application requirements.
3. Protection type: short circuit/overload/overvoltage, over temperature (except MFM-30).
4. Extremely low leakage current, no-load power consumption <0.075~0.1W.
5. EMI Class B for Class II configuration.
6, the widest range of operating temperature -40 ~ +85 ℃, micro size, high power density.
It can provide 110 percent peak power for 10 seconds with no minimum load requirement.
8, 3 years warranty.
