Description
Output voltage: 5V Output current: 0 ~ 30A Rated power: 150W Rated DC input: 48VDC Input voltage: 36 ~ 75VDC Input surge voltage (max. 100ms):100VDC Size (mm):57.9X61X12.7
Click to download Airtac product catalog
Product Features
1. Half brick size (2.28 "x 2.4" x 0.5 "), using industry standard output pin pin, 2:1 wide input range.
2. Protection type: short circuit/over current/over voltage/over temperature, efficiency up to 89%.
3. 1500VDC input/output isolation, with remote control switch, with remote sensing function.
4. The output is adjusted by 10%, and the metal protective shell is 5. Optional heat sink can be provided to improve the working temperature.
5.3.3V/15V output available, safety certification: UL/CUL/EAC/CE/UKCA,3 years warranty.
