Description
PCB mounting type Rated power: 30.2W Input voltage: 80 ~ 264VAC Output voltage: 48V Output current: 0.63A Peak current: 0.73A Peak load (10 seconds):35W Size (mm):69.5X39X24
Click to download Airtac product catalog
Product Features
1. International universal full range input: 85 ~ 264VAC.
2. Full protective plastic shell, medical safety certification (2xMOPP), suitable for BF grade application requirements.
3. Protection type: short circuit/overload/overvoltage/over temperature, very low leakage current.
4. No-load power consumption:<0.075~0.1W.
5. EMI Class B for Class II configuration.
6, the widest range of operating temperature -40 ~ +85 ℃, micro size, high power density.
7. Can provide 110% peak power for 10 seconds.
8, glue, dust, moisture, shock, no minimum load requirements, 3 years warranty.
