Description
Screw terminal block type Output DC voltage: 24V Peak output current (10 seconds):2.98A Output current natural air cooling: 2.71A Peak output power rating (10 seconds):71.5W Output rated power natural air cooling: 65W Input voltage: 80 ~ 264VAC,113 ~ 370VDC Size (mm):109X52X33.5
Click to download Airtac product catalog
Product Features
1. International universal full range input: 85 ~ 264VAC.
2. Full protective plastic shell, medical safety certification (2xMOPP), suitable for BF grade application requirements.
3. Protection type: short circuit/overload/overvoltage/over temperature, very low leakage current.
4. No-load power consumption:<0.075~0.1W.
5. EMI Class B for Class II configuration.
6, the widest range of operating temperature -40 ~ +85 ℃, micro size, high power density.
7. Can provide 110% peak power for 10 seconds.
8, glue, dust, moisture, shock, no minimum load requirements, 3 years warranty.
