Description
Output channel: CH2 Output voltage: 24V Rated current: 2.7A Output current minimum load: 0.3A Output current natural cooling (maximum):2.1A Output Current Fan Air Cooled (25CFM):2.7A Output current Max load with 25CFM Fan: 3.3A Input voltage: 90 ~ 264VAC,47~63Hz/127 ~ 370VDC Size (mm):177 X107.2X35.5
Product Features
1, 4 "x 2", 5 "x 3" general use small size.
2, Class I or Class II configuration, through the medical class safety certification (2xMOPP).
3. Built-in active PFC(RPT-160, MPQ-200), suitable for BF level application requirements.
4. Very low leakage current, built-in P.G and P.F signal output (RPT-160).
5. No-load power consumption <0.1W ~ 0.75W, protection type: short circuit/overload/overvoltage, over temperature (RPT-160).
6. 5V0.8A spare output (RPTG-160).
7. LED power on indicator (RPT-160/MPQ-200 only).
8, 3 years warranty.
