Description
Front End Input voltage range: 90 ~ 264VAC,120 ~ 370VDC Output frequency range: 47~63Hz Input AC current: 3.5A/230VAC,7.5A/115VAC Input inrush current: 40A/230VAC,25A/115VAC Total output power: 650W (maximum) Size:(mm):250X89X41
Product Features
1. International universal full range input: 90 ~ 264VAC.
2. Passed medical safety certification (2 * MOPP), suitable for BF grade application requirements (contact current <100 µA/264VAC),1U low shell.
3. 1U low housing, programmable output voltage and current.
4. Built-in parallel function.
5. Remote local on-off/auxiliary DC output.
6. over temperature alarm/DC OK signal, built-in temperature control fan cooling with fan alarm function.
7. Protection type: short circuit/overload/overvoltage/over temperature protection of all output modules.
8 and 5 years warranty.
