Description
Output average charging voltage (default):28.8V Output float voltage (default):27.6V Output charging voltage range: 21~42V Maximum output current: 0 ~ 36A Maximum power: 1209.6W Recommended battery capacity (Ah):120 ~ 420AH Input voltage: 90 ~ 264VAC,127 ~ 370VDC Size (mm):250X158X67
Product Features
1. International universal full range input: 90 ~ 264VAC.
2, 2 times the wide range of charging voltage, a machine with a variety of battery voltage, intelligent detection of charging voltage.
3. The 2/3 section charging curve can be programmed through the SBP-001, and the 2/3 section charging and 4 preset charging curves can be manually set through DIP S.W.
4. The built-in CANbus communication interface is used for control, setting and monitoring. The charging current can be adjusted within the range of 50~100% through VR.
5. -30~70 ℃ wide working temperature, protection type: short circuit/overvoltage/overtemperature/battery undervoltage/battery reverse polarity protection (no damage).
6. TTL detection charger OK and battery full signal, remote control switch/thermal control DC fan, temperature compensation function can extend battery life (lead-acid only).
7. Through UL/EN62368-1 and EN60335-1/2-29 double safety certification, suitable for lead-acid batteries and lithium batteries.
8. Handle accessories (order model: Carry handle) can be purchased separately with a 3-year warranty.
