Description
Output voltage: 36V Output constant current range: 21.6~36V Rated output current: 1.12A Output power rating: 40.32W Function: constant current output, with three-in-one dimming function Input voltage: 90 ~ 305VAC,127 ~ 431VDC Size (mm):150X53X35
Product Features
1. Constant current mode + constant voltage mode output, D-Type only constant current mode, V-Type only constant voltage mode; D-Type built-in three-in-one dimming function (1 ~ 10VDC,PWM signal, resistance).
2. International common input range: 90 ~ 305VAC.
3. Built-in active PFC function.
4, the highest efficiency can reach 94%.
5. No-load consumption <0.15W(D-Type<0.5W).
6. Fully enclosed plastic shell, meet IP67 grade.
7. Class II design, no FG;Class 2 power supply.
8. Protection type: short circuit/over current/over voltage/over temperature, 5 years warranty.
