Description
Power supply electrical specifications (switchable via pins 3 and 4 of the 14-pin connector on the panel) Output DC voltage: 72V Output voltage adjustment range: 54~100V, through the built-in potentiometer Output current regulation range: 2.75 ~ 5.5A Rated current: 5.5A Rated power: 462W Input voltage: 90 ~ 264VAC,127 ~ 370VDC Size (mm):205X135X55
Product Features
1. International universal full range input: 90 ~ 264VAC.
2. Constant voltage supply and load of charger or power supply can be switched (pin is inserted on the panel), and 2 times wide voltage output.
3. The output voltage and current can be adjusted in the range of 50~100% through VR, 3-stage charging curve (charging mode).
4. -30~70 ℃ wide working temperature, protection type: short circuit/overvoltage/overtemperature/overload.
5. Remote control switch/thermal control DC fan, suitable for lead-acid batteries and lithium batteries.
6. Through UL/EN62368-1 and EN60335-1/2-29 double safety certification.
7. Handle accessories can be purchased separately (order model: Carry handle).
8, 3 years warranty.
