Description
AC output power rating (continuous):2200W AC output over power (3 minutes):2530W AC output peak power (10 seconds):3300W AC instantaneous power (30 cycles):4400W AC output AC voltage: factory set at 110VAC,100/110/150/120VAC can be selected by DIP S.W AC output frequency: factory set at 60Hz ± 0.1Hz,50/60Hz can be selected by DIP S.W DC input DC voltage: 48VDC DC input voltage range (Typ.):40 ~ 66VDC DC input DC current (Typ.):60A Size (mm):420X270X98 AC output socket type: global
Product Features
1. High frequency design, small size, light weight and portable, built-in type (NTS-250P/400P), pure sine wave output (THD<3%).
2. Instantaneous output power up to 200%, no fan design, natural air cooling, no noise (NTS-250P/400P/300).
3. The AC output voltage and frequency can be adjusted by DIP S.W on the panel, and the no-load power consumption in standby power saving mode is <1.2~1.7W (depending on the model).
4. -25~70 ℃ wide working temperature, protection function: DC input: reverse polarity/DC low voltage alarm/DC low voltage shutdown/overvoltage, AC output: short circuit/overload/overtemperature.
5. Remote control on/off power supply, remote control (IRC1,IRC2,IRC3, accessories sold separately, suitable for 750W ~ 3200W).
6. Support RS-232 communication (750W ~ 3200W, communication line DS-RJ11-RS232 sold separately), built-in Tx/Rx monitoring inverter status (only NTS-250P/400P).
7. Handle accessories (model DS-Carry handle, sold separately), suitable for lead-acid batteries or lithium-ion batteries.
8. Internal PCB board, with coating protection, 3 years warranty.
