MEAN WELL PLM-25 series: single output LED control device - PLM-25-1050

Description

Output constant current range: 14~24V Rated output current: 1.05A No-load output voltage (maximum):28V Rated power: 25.2W Input voltage: 110 ~ 295VAC,156 ~ 417VDC Input frequency: 47~63Hz Size (mm):145X38X22

Click to download Airtac product catalog

Product Features

1. Full range AC input (up to 295VAC) model, with active PFC function, constant current design, protection mode: short circuit, natural air cooling.

2. Fully protective plastic shell, Class II power supply, no FG,Class 2 power supply (PLM-25-500-700-1050 only), no-load consumption <0.5W, high reliability, low cost, 2-year warranty.

MEAN WELL PLM-25 series: single output LED control device - PLM-25-1050

Product form

Output constant current range: 14~24V Rated output current: 1.05A No-load output voltage (maximum):28V Rated power: 25.2W Input voltage: 110 ~... Read more

$36.00 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Output constant current range: 14~24V Rated output current: 1.05A No-load output voltage (maximum):28V Rated power: 25.2W Input voltage: 110 ~ 295VAC,156 ~ 417VDC Input frequency: 47~63Hz Size (mm):145X38X22

    Click to download Airtac product catalog

    Product Features

    1. Full range AC input (up to 295VAC) model, with active PFC function, constant current design, protection mode: short circuit, natural air cooling.

    2. Fully protective plastic shell, Class II power supply, no FG,Class 2 power supply (PLM-25-500-700-1050 only), no-load consumption <0.5W, high reliability, low cost, 2-year warranty.
