PLM-25-350 — Constant-current LED power supply

MEAN WELL PLM-25-350 is a single-output constant-current LED power supply rated at 0.35 A (350 mA), with a 42–72 V DC operating region and 25.2 W rated output. It accepts 110–295 VAC or 156–417 VDC and combines active PFC with a fully isolated plastic case and free-air convection cooling.

Download MEAN WELL PLM-25 Datasheet (PDF)
Download MEAN WELL LED Installation Manual (PDF)
Download MEAN WELL EMI Testing Guidance (PDF)

PLM-25: PDF pages 5–8.

Output and load selection

Output mode Single-output constant-current design.
Constant-current operating region 42–72 V DC. Use this model-specific region for LED load selection.
Rated output current 0.35 A (350 mA).
Rated output power 25.2 W.
No-load output voltage 80 V maximum.
Ripple and noise 7.2 Vp-p maximum. Measured with 20 MHz bandwidth and a 12-inch twisted-pair lead terminated with 0.1 µF and 47 µF capacitors in parallel.
Current accuracy ±5.0%; also observe the AC-input-drop response below.
Setup time 500 ms at 115 VAC or 230 VAC, at full load.
Load application Indoor LED lighting, including office, commercial and decorative lighting. Direct connection to LEDs is suggested; the supply is not suitable for use with additional drivers. Confirm any special electrical requirements of the final system.
Constant-current selection note The datasheet describes the constant-current region generally as 60–100% of rated output voltage; use the explicit model-specific operating region above when selecting the LED string.

Input and efficiency

Input voltage 110–295 VAC or 156–417 VDC.
Input frequency 47–63 Hz.
Power factor Built-in active PFC. At full load: PF ≥0.97 at 115 VAC, ≥0.95 at 230 VAC and >0.9 at 277 VAC.
Total harmonic distortion THD <20% with output loading ≥60% at 115 VAC or 230 VAC, and ≥75% at 277 VAC.
Efficiency 87% typical for this model.
AC input current 0.3 A at 115 VAC; 0.15 A at 230 VAC; 0.12 A at 277 VAC.
Inrush current 15 A typical cold start at 230 VAC; pulse width 50 µs measured at 50% of peak current.
Leakage current 0.25 mA at 240 VAC.
No-load consumption Less than 0.5 W.
AC voltage-drop response AC input drops of 10%, 8%, 5% and 3% correspond to output-current drops of <16%, <12%, <8% and <7%, respectively. Output current returns to the rated value within 50 ms.
Performance-curve scope The PLM-25 constant-current power-factor curves show 60–100% load at 110, 230 and 277 VAC. The efficiency-versus-load graph on PDF page 8 applies specifically to the 500 mA model; use the typical efficiency specified above for this model.

Protection and environment

Short-circuit protection Hiccup mode; automatic recovery after the fault condition is removed.
Cooling Free-air convection.
Working temperature −30 to +45°C.
Ambient-temperature load curve The horizontal-mounting curve permits 100% load from −30 to +45°C. The stated operating range ends at +45°C.
Input-voltage load curve The static-characteristic curve shows 100% load across 110–295 VAC. Apply the stated operating-temperature and load limits together.
Working humidity 20–90% RH, non-condensing.
Storage conditions −40 to +80°C; 10–95% RH.
Temperature coefficient ±0.06%/°C over 0–50°C; this characterization interval does not extend the stated operating-temperature range.
Vibration 10–500 Hz, 2 G, 10 minutes per cycle, for 60 minutes along each of the X, Y and Z axes.

Safety, EMC and reliability

Power-unit classification Class II power unit with no FG terminal; SELV; IP30. The series Class 2 designation is limited to PLM-25-500, PLM-25-700 and PLM-25-1050; it does not apply to PLM-25-350.
Safety standards UL8750; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384; EAC TP TC 004; IP30 approved, as stated in the datasheet.
Optional CCC configuration CCC-certified versions to GB/T19510.1, GB/T19510.213, GB/T17743 and GB17625.1 are optional; contact MEAN WELL to confirm the required supplied configuration.
Withstand voltage Input to output: 3.75 kVAC.
Isolation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH.
EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at ≥60% load; BS EN/EN61000-3-3; EAC TP TC 020.
EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level, criteria B (2 kV surge); EAC TP TC 020.
Reliability Minimum MTBF: 7905.4 thousand hours by Telcordia SR-332 (Bellcore), and 608.9 thousand hours by MIL-HDBK-217F at 25°C.
Series design The manufacturer describes this as an economical, high-reliability series for LED lighting and states compliance with the ErP requirements for lighting fixtures.
Manufacturer warranty 2 years.

Construction, terminals and dimensions

Construction Fully isolated plastic case, with UL 94V-0-rated flame-retardant material and screwless clamp-style terminal-block input and output.
Dimensions 145 × 38 × 22 mm (L × W × H). Mechanical drawing: Case No. PLM-25; general tolerance ±1 mm.
Mounting drawing The two diagonal open mounting features are marked Ø3.5 mm, with 4.5 mm edge-position references. The side view also marks a 3.5 mm local base/flange dimension; follow the dimensioned drawing for installation.
Case-temperature measurement point The marked Tc point is 65 mm from the right-hand end and 12 mm from the lower edge in the plan view. These are location dimensions, not temperature ratings.
AC input terminal block TB1: SWITCHLAB MWX201-75002EB (gray). Pin 1 = AC/L; pin 2 = AC/N.
DC output terminal block TB2: SWITCHLAB MWX201-75002B (blue). Pin 1 = +V; pin 2 = −V.
Recommended wiring The mechanical drawing suggests UL1015 18 AWG × 2-core wire for both the input and output connections.
Accessory scope The series datasheet specifies the terminal blocks and recommended wiring, but gives no separate MEAN WELL accessory ordering code. The recommended wire specification is not a claim that cables are included.
Packing and weight 126 g (0.126 kg), catalog packing reference per unit; not a measured net-weight claim. Outer packing: 60 pieces, 8.6 kg, 0.48 CUFT.
General test conditions Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient temperature.

Installation and system guidance

Installation isolation and service Disconnect the supply from the mains before installation or maintenance and prevent unintended reconnection. Have faults examined by a qualified technician; do not open the case yourself. Dispose of the LED supply together with the lighting equipment at end of life.
Ventilation and mechanical support Keep ventilation clear and do not stack objects on the unit. Maintain 10–15 cm clearance when an adjacent device is a heat source. Follow this model’s mounting orientation and derating diagrams. Check the mounting surface and luminaire structural strength; use safety cables for bay lighting applications. Do not immerse the unit in water.
Wiring and system enclosure Use approved input and output wiring with current ratings at least equal to the applicable unit current. Follow this model’s terminal assignments. This Class II ungrounded power supply has no FG terminal. Provide insulation around system interconnections and enclose single-insulated wiring. Keep output current and power within the model ratings and temperature limits. Have damaged external flexible cables replaced by the manufacturer, its service agent or similarly qualified personnel.
Circuit-breaker reference At 230 V AC, the installation manual gives calculated maximum quantities for PLM-25 with ABB S200-series breakers: B10 50, B16 80, C10 50, C16 80, D10 50 and D16 80. B, C and D identify breaker trip curves; 10 and 16 identify ampere ratings. These counts apply to that stated breaker and voltage reference.
EMC integration Reverify EMC in the finished equipment with the connected load and actual wiring and assembly. The linked guidance describes representative component-power-supply tests; its illustrated distances are test arrangements, not installation clearances.
