Description
5 "X3" 3 group output Output channel: CH2 Output voltage: 12V Rated output current: 1.6A Output current range: 0.2 ~ 2.3A Rated power: 43.5W Output power (maximum): rated power for natural air cooling; 52W @ input voltage when fan air volume is greater than 18CFM forced air cooling: 90 ~ 264VAC or 127 ~ 370VDC Size (mm):127X76X28
Product Features
1. International universal full range input: 90 ~ 264VAC.
2. Built-in active PFC(PPT-125).
3. Optional L-shaped bracket and casing (RPT-65 series).
4. Leakage current <1mA(RPT-65 series).
5. PWM control adjustment (PPT-125).
6. Protection type: short circuit/overload/over temperature (except RPT series)/over voltage (except PT series).
7, 2 years warranty.
8, 3 years warranty (PPT-125).
