Description

MEAN WELL QP-320D is a quad-output AC/DC power supply with CH1 5 V, CH2 12 V, CH3 24 V, CH4 -12 V and 316 W rated combined output. It provides active PFC, fan cooling and remote sense for CH1/CH2. PG/PF signal output is listed. Select loads using the continuous channel-current ranges, the combined-power rating and the separately stated peak-current conditions.

Product Datasheet

Download MEAN WELL QP-320 Datasheet (PDF)

The QP-320 section is on PDF pages 10, 11. Refer to the complete mechanical drawings and notes when planning installation.

Model and Four-Output Configuration

Complete model QP-320D
Output rails CH1 5 V, CH2 12 V, CH3 24 V, CH4 -12 V
Rated combined output 316 W across all four channels
Channel loading Use the specified current ranges, combined-power limit and applicable input/temperature derating together.

The complete suffix identifies the output-voltage combination. Negative outputs retain their listed polarity relative to COM; current values are load-current magnitudes. The four channels form one power supply, not four independently rated supplies. The series number is not the exact rated combined power of every model.

Four-Channel Electrical Specifications

CH1 voltage and current 5 V DC; rated current 20 A; continuous current range 2.5–20 A.
CH1 ripple and regulation Maximum ripple/noise 100 mVp-p; voltage tolerance ±3.0%; line regulation ±1.0%; load regulation ±2.0%.
CH2 voltage and current 12 V DC; rated current 10 A; continuous current range 0–10 A.
CH2 ripple and regulation Maximum ripple/noise 150 mVp-p; voltage tolerance ±3.0%; line regulation ±2.0%; load regulation ±3.0%.
CH3 voltage and current 24 V DC; rated current 3 A; continuous current range 0.2–5 A.
CH3 ripple and regulation Maximum ripple/noise 150 mVp-p; voltage tolerance +10/-6%; line regulation ±2.0%; load regulation ±6.0%.
CH4 voltage and current -12 V DC; rated current 2 A; continuous current range 0.2–2 A.
CH4 ripple and regulation Maximum ripple/noise 150 mVp-p; voltage tolerance ±10%; line regulation ±3.0%; load regulation ±8.0%.
CH1 / CH2 voltage adjustment CH1 4.75–5.5 V; CH2 11.4–13.2 V, corresponding to −5%/+10% of nominal voltage.
Typical efficiency 83% at the catalogue reference conditions.

Unless otherwise stated, specifications use 230 VAC input, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured at 20 MHz bandwidth using a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors.

Keep the normal combined load within the model total-power rating. Each output maximum is a channel limit, not permission to load all channels to their individual maximum currents simultaneously. The stated CH1 and CH2 adjustment and sense functions do not make their outputs exempt from these limits.

Conditional CH3 Peak-Current Capability

Peak-current row CH1 20 A, CH2 10 A, CH3 20 A, CH4 2 A
CH3 peak duration / repetition CH3 at nominal 24 V: 20 A for no more than 1 ms, repeatable every 100 ms.
CH3 voltage during peak The 24 V output must remain above 16 V during the peak-current period.

The 20 A figure is a short CH3 pulse capability, not a continuous current rating or a guarantee of regulated 24 V during that pulse. Apply the specified pulse duration, repetition and minimum pulse voltage together. Normal combined loading must not exceed the rated total output power; maximum individual channel currents are not simultaneous entitlements.

Input, PFC and Timing

Input / frequency 90–264 VAC, universal full range; 127–370 VDC. AC frequency 47–63 Hz.
Power factor, typical Active PFC: PF >0.95 at 230 VAC and >0.98 at 115 VAC, full load.
Typical input current 4 A at 115 VAC; 2 A at 230 VAC.
Inrush / leakage Typical inrush 25 A at 115 VAC / 45 A at 230 VAC; leakage <2 mA at 240 VAC.
Setup / rise time 800 ms / 50 ms at 230 VAC; 3000 ms / 50 ms at 115 VAC, full load.
Typical hold-up time 16 ms at full load.
Switching frequency 100 kHz as shown in the block diagram.

The timing and inrush entries without separately labelled input voltages retain the general catalogue reference conditions; do not infer an additional unprinted input-voltage test.

Protection and Signal Availability

Short circuit / overload Short-circuit protection is listed. Overload threshold is 105–150% of rated output power; foldback current limiting, automatically recovering after the fault is removed.
Over-voltage CH1 5.75–6.75 V; CH2 13.8–16.2 V. Output shuts down; re-power to recover.
Over-temperature Output shuts down and automatically recovers after temperature decreases.
Power good / power fail PG/PF signal output is listed: 10 ms / 1 ms.

PG/PF uses CN2 pin 5 with pin 6 GND. These pages do not specify its voltage levels, polarity or current capability; verify the signal-interface details before connection rather than applying TTL or relay ratings from another series.

The protection thresholds describe fault response, not an unrestricted higher output-power operating mode.

Cooling and Derating

Cooling / working temperature Built-in DC fan with forced-air cooling; −10 to +70°C ambient, subject to derating.
Horizontal thermal curve 100% load from −10 through +50°C; derate to 40% at +70°C.
Input-voltage curve at 60 Hz 80% load at 90 VAC, rising to the plotted plateau at 105 VAC. The plateau remains below the 100% tick through 264 VAC; use the actual curve for the allowable load.
High-altitude adjustment Above 2000 m, reduce the allowable ambient temperature by 5°C for each additional 1000 m for this fan-cooled design.

Apply temperature and input-voltage derating together with all channel and total-power limits. Keep the illustrated upward airflow path unobstructed. The upper working temperature is not a full-load temperature rating. The altitude note does not state a separate maximum operating altitude.

Use the QP-320 curve for this model; the lower-power QP families have different thermal and low-line limits.

Power Terminals and Remote Sense

AC input / earth Terminal 1 = AC/L; 2 = AC/N; 3 = FG protective earth.
DC output terminals 4 = V4 (CH4); 5 = V3 (CH3); 6 = V1 (CH1); 7 and 8 = output COM; 9 = V2 (CH2).
CH1 sense pair CN2 pin 1 = V1(+S); pin 2 = V1(−S).
CH2 sense pair CN2 pin 3 = V2(+S); pin 4 = V2(−S).
Signal pins CN2 pin 5 = PF/PG; pin 6 = GND.

Remote sense is provided for CH1 and CH2 only. Match each sense pair to its corresponding output and load return, using the actual connection arrangement. The catalogue pages do not quantify a compensation-voltage limit or show default sense jumpers, so neither is assumed here. Sense and signal pins are not load-current output terminals.

The two COM power terminals share the output reference; they are not additional output channels. Use the complete mechanical drawing for terminal orientation. No remote ON/OFF, programmable current or parallel-sharing interface is established by these pages.

Connector References and Installation

CN2 board connector JST S6B-XH-A-1 or equivalent.
Mating housing as printed JST XHP or equivalent; the catalogue does not print a complete pin-count/order suffix.
Crimp contact JST SXH-001T-P0.6 or equivalent.
Selection / supply boundary Confirm the full compatible housing code, contact and wire specification before ordering. These printed references do not establish that mating housings, contacts or a harness are included.

The connector table gives an incomplete XHP housing designation; do not add a guessed suffix. The power-terminal assignments and CN2 control-pin assignments are separate. There is no separately specified mounting-kit or cable-kit order code in this section.

Dimensions, Mounting and Weight

Body dimensions / case 215 × 115 × 50 mm (L × W × H); case 912I. Drawing tolerance ±1 mm.
Mounting-thread callouts 4-M4 L=5mm; 6-M3 L=3mm; 6-M4 L=5mm.
Mechanical references Body width 115 mm; extended mounting footprint 135 mm; longitudinal reference dimensions 117.5, 150 and 177.5 mm. Use their actual drawing locations.
Terminal projection / spacing Terminal projection 13 mm maximum; terminal-area dimension callouts include 9.5 mm and 8 mm at their illustrated locations.
Single-unit weight reference 1.2 kg (1200 g); catalogue packing: 12 pieces / 15.4 kg / 0.9 CUFT.

The drawing marks an LED and V1/V2 adjustment controls. Mounting-hole counts are drawing features, not supplied screw quantities. Use the stated thread/depth callouts at their corresponding positions; these pages do not specify a mounting torque.

The weight is the explicit single-unit PACKING reference, not a measured bare net weight or the total carton mass. The main body dimensions and the mounting/terminal projections are separate measurements.

Environment, Safety and EMC

Humidity / storage Operating humidity 20–90% RH; storage −20 to +85°C and 10–95% RH; non-condensing.
Temperature coefficient / vibration ±0.03%/°C from 0 to 50°C. Vibration: 10–500 Hz, 2G, 10 minutes per cycle and 60 minutes on each X, Y and Z axis.
Safety standards UL62368-1, TUV BS EN/EN62368-1 and EAC TP TC 004, as listed in this datasheet.
Dielectric strength I/P–O/P 3 kVAC; I/P–FG 2 kVAC; O/P–FG 0.5 kVAC.
Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH across I/P–O/P, I/P–FG and O/P–FG.

Emissions: BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2 and -3-3, and EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN55035 light-industry level and EAC TP TC 020. No unlisted test severity is inferred.

The power supply is a component for installation in final equipment, which must be checked again for applicable EMC compliance. Catalogue EMC testing used a 360 × 360 mm metal plate, 1 mm thick.

Reliability and Manufacturer Warranty

Minimum MTBF 1477.2 thousand hours by Telcordia SR-332 (Bellcore); 213.6 thousand hours by MIL-HDBK-217F at 25°C.
Manufacturer warranty Three years as stated in the datasheet, subject to the applicable manufacturer terms.
Production test 100% full-load burn-in is listed in the product features.

MTBF is a statistical reliability reference, not a guaranteed operating lifetime.
