Description
Series: Double group output Rated power: 8W Input voltage (range): standard voltage 24V(9~36V) Input current no-load: 15mA, full load: 390mA Output voltage: ± 15V Output current: ± 0 ~ 265mA Efficiency (TYP.):85% Capacitive load (max):* 265μF Size (mm):31.8X20.3X10.2
Click to download Airtac product catalog
Product Features
1. In line with EN50155 railway standards, DIP24 package, industry standard pins.
2.4:1 wide input range, operating temperature range -40~85 ℃, no minimum load required.
3. Closed type, protection: short circuit (continuous)/overload/overvoltage/input undervoltage, 1.5KVDC input/output isolation, remote on/off, 3-year warranty.
