Description
Output average charge voltage Vboost (preset):28.8V Output float voltage Vfloat (preset):27.6V Constant current (CC)(default):0 ~ 55A Output voltage adjustment range: 23.5~30V, through the internal potentiometer SVR Recommended battery capacity (AMP HOURS):180 ~ 550Ah Battery leakage current (Typ.):<1mA Input voltage: 90 ~ 264VAC,250 ~ 370VDC Size (mm):300X85X41 Communication protocol: PMBus protocol, standard product
Product Features
1. International universal full range input: 90 ~ 264VAC.
2, 3-stage charging curve, can withstand 300VAC surge input up to 5 seconds.
3. It has I²C interface and PMBus communication protocol (CANBus protocol is optional).
4, 1U low appearance, height only 41mm, rack mounted, parallel up to 8000W(RCB-1600).
5. Active current sharing function, up to 4800W(RPB-1600) in parallel.
6. The output voltage and current value are adjustable, built-in DC fan, forced air cooling, built-in OR-ing FET, support hot swap.
7. Protection type: short circuit/overvoltage/overtemperature/battery low voltage/battery no connection.
8, 3-color LED loading indicator, optional spray moisture, commonly used in lead-acid batteries, lithium battery charging, 5 years warranty.
