Description
4 "X2" package Output power rating: 60W Input voltage: 90 ~ 264VAC,127 ~ 370VDC Output voltage: 15V Output rated current: 4A Output current range: 0 ~ 4.4A Peak load (10 seconds):66W Size (mm):101.6X50.8X29
Product Features
1, 3 "x 2", 4 "x 2", 5 "x 3" general use small size, Class I or Class II configuration.
2. Through medical safety certification (2xMOPP), built-in active PFC(RPS-120S/160/200).
3. Suitable for BF grade application requirements, very low leakage current.
4. Built-in P.G and P.F signal output (RPS-160), with remote voltage compensation function (RPS-160 5~15V).
5. No-load power consumption <0.1W ~ 0.75W, protection type: short circuit/overload/overvoltage, over temperature (120~200W).
6.12V fan auxiliary power supply (RPS-120/200),5V/0.8A backup output (RPSG-160).
7, LED power start indicator (except RPS-60), can provide 110~125 peak power.
8, 3 years warranty.
