MEAN WELL RPS-60 series: Open-Frame Medical AC/DC Power Supply - RPS-60-48

Description

MEAN WELL RPS-60-48 is an open-frame medical AC/DC power supply rated at 48 V, 1.25 A and 60 W. Its 4 × 2-inch PCB format uses free-air convection cooling and Class I construction with protective grounding. Primary-to-secondary insulation is specified as 2 × MOPP; BF use requires appropriate consideration of the complete medical system. Continuous and short-duration output limits are given separately below.

Product Datasheet

Download MEAN WELL RPS-60 Datasheet (PDF)

The RPS-60 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation.

Model and Product Configuration

Exact model RPS-60-48.
Product type Open-frame, PCB-type medical AC/DC power supply with a single DC output and free-air convection cooling.
System protection class Class I, with FG.
Typical integration applications Medical computer monitors, oral irrigators, hemodialysis machines and sleep-apnea equipment, subject to the finished system’s safety assessment.

Select by the complete model and the actual ratings below. The series number does not replace the model-specific continuous power rating.

Model-Specific DC Output

DC output voltage 48 V.
Rated current 1.25 A.
Printed current range 0–1.375 A; the part above rated current is subject to the short-duration peak rating.
Rated output power 60 W, as printed for this exact model.
Peak load 66 W for 10 seconds maximum, subject to the conditions below.
Ripple and noise, maximum 100 mVp-p.
Output-voltage adjustment 45.6–52.8 V.
Voltage tolerance ±1.0%; includes set-up tolerance, line regulation and load regulation.
Line regulation ±0.5%.
Load regulation ±1.0%.
Efficiency, typical 86%.

The printed peak-load rating is 66 W for no more than 10 seconds. It is not a continuous rating. Peak duty cycle must not exceed 33% within every 30 seconds, and average output power must not exceed this model’s rated power. These limits apply together.

Unless stated otherwise, parameters are measured at 230 VAC, rated load and 25°C ambient. Preserve the printed power and current limits together rather than increasing either limit through rounding.

Ripple and noise are measured at 20 MHz bandwidth using a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors.

Input, Timing and Leakage

Input range 90–264 VAC or 127–370 VDC. Apply the input-voltage derating curve.
AC frequency 47–63 Hz.
Input current, typical 1.8 A at 115 VAC; 1 A at 230 VAC.
Cold-start inrush, typical 30 A at 115 VAC; 60 A at 230 VAC.
No-load power consumption Less than 0.75 W.
Set-up and rise time 500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, full load.
Hold-up time, typical 60 ms at 230 VAC; 12 ms at 115 VAC, full load.
Leakage current Earth leakage less than 150 µA at 264 VAC; touch current less than 100 µA at 264 VAC. Touch current is measured from primary input to DC output.
Block-diagram frequency 100 kHz switching-frequency reference.

Protection

Short circuit and overload Short-circuit protection is listed. Overload threshold: 115–150% of rated output power; hiccup mode recovers automatically after the fault is removed.
Overvoltage threshold 55.2–64.8 V.
Overvoltage recovery Output voltage shuts down; re-power on to recover.

Protection thresholds are not extra continuous-output allowances. Apply the model-specific continuous and peak limits as well as temperature and input-voltage derating.

Cooling, Derating and Environment

Cooling and working ambient Free-air convection; −20 to +70°C with derating.
Horizontal temperature/load curve 100% load from −20 to +50°C, reducing to 50% at +70°C.
Input-voltage/load curve, 60 Hz 80% load at 90 VAC, rising to 100% at 115 VAC; 100% plateau through 264 VAC.
Humidity and storage Working: 20–90% RH, non-condensing. Storage: −40 to +85°C and 10–95% RH, non-condensing.
Temperature coefficient ±0.03%/°C over 0–50°C.
Vibration 10–500 Hz, 2 G, 10 minutes per cycle; 60 minutes each along X, Y and Z.
Operating altitude 3000 m maximum. Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless supply.

Apply temperature and input-voltage limits together. Use the complete plotted curves for intermediate conditions; the upper operating temperature is a derated point, not a full-power rating.

Dimensions, Installation and Connectors

Dimensions, L × W × H 101.6 × 50.8 × 29 mm.
PCB footprint and mounting holes 4 × 2 inches; four Ø3.3 mm holes on a 95.25 × 44.45 mm centre pattern, with 3.175 mm edge offsets.
Drawing orientation and clearance Top-view connector numbering; dimensions in millimetres, general tolerance ±1 mm unless noted. The side view separately marks underside projections of 3 mm maximum; allow clearance according to the complete drawing.
AC input connector CN1 JST B3P-VH or equivalent. Pin 1: AC/N; pin 2: no pin; pin 3: AC/L.
DC output connector CN2 JST B4P-VH or equivalent. Pin 1: +V; Pin 2: +V; Pin 3: −V; Pin 4: −V.
Mating connector references Housing: JST VHR or equivalent, as printed. Terminal: JST SVH-21T-P1.1 or equivalent. The VHR reference is a series name; select the exact housing position count and compatible terminal for CN1 or CN2.
Board component references FS1 and FS2: T2.5/250V, as marked in the drawing. SVR1 is the output-voltage adjustment reference.
Grounding and heatsinks Class I installation requires grounding. M1 is safety ground; for better EMC performance, establish an electrical connection between M1, M2 and chassis grounding. Do not short HS1 and HS2.

The connector, housing and terminal references identify interface parts for selection; the catalogue does not state that loose mating housings, terminals, cables or mounting hardware are included. Select the compatible position count and wiring arrangement without inventing unprinted ordering suffixes. The duplicated +V or −V pins, where present, belong to the same single output. Use the complete mechanical drawing and installation instructions.

Safety and EMC

Medical safety standards listed as approved IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004.
Isolation and BF application Primary-to-secondary isolation: 2 × MOPP. Suitable for BF applications with appropriate system consideration; this component does not by itself establish BF compliance of the complete medical equipment.
Withstand voltage Input-to-output: 4 kVAC. Input-to-FG: 2 kVAC; output-to-FG: 1.5 kVAC.
Insulation resistance Input-output, input-FG and output-FG: 100 MΩ at 500 VDC, 25°C and 70% RH.
Additional insulation and IT approvals Primary-to-earth: 1 × MOPP; secondary-to-earth: 1 × MOPP. Approved IT standards listed: IEC62368-1:2014; UL62368-1, 2nd Ed; CSA C22.2 No.62368-1-14, 2nd Ed; TUV BS EN/EN62368-1:2014+A11.
Emissions and system configuration BS EN/EN55011 (CISPR11) conducted and radiated emissions: Class B in Class I configuration. Harmonic current: BS EN/EN61000-3-2 Class A; voltage flicker: BS EN/EN61000-3-3.

Immunity is specified to BS EN/EN55035 and BS EN/EN60601-1-2. BS EN/EN61000-4-2 ESD: level 4, 15 kV air and 8 kV contact; -4-3 RF: level 3, 10 V/m over 80 MHz–2.7 GHz, plus Table 9 fields of 9–28 V/m over 385 MHz–5.78 GHz.

BS EN/EN61000-4-4 EFT: level 3, 2 kV; -4-5 surge: level 4, 4 kV line-to-FG and 2 kV line-to-line; -4-6 conducted susceptibility: level 3, 10 V; -4-8 magnetic immunity: level 4, 30 A/m. BS EN/EN61000-4-11: 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods.

The catalogue EMC tests used the unit mounted on a 360 × 360 mm metal plate, 1 mm thick. Confirm EMC compliance again in the final assembled equipment.

Weight, Reliability and Catalogue

Single-unit catalogue weight 150 g (0.15 kg), explicitly stated in PACKING; this is a catalogue unit reference, not a measured shipping-parcel weight.
Packing reference 96 pieces / 15.4 kg / 0.89 CUFT.
Minimum MTBF estimates 5153.0 thousand hours by Telcordia SR-332 (Bellcore); 353.6 thousand hours by MIL-HDBK-217F at 25°C.
Warranty and applicable version 3-year manufacturer warranty, subject to applicable terms. RPS-60-SPEC dated 2026-02-28; combined PDF pages 17–20.

MTBF is a statistical reliability estimate, not a guaranteed service life.

MEAN WELL RPS-60 series: Open-Frame Medical AC/DC Power Supply - RPS-60-48

Product form

MEAN WELL RPS-60-48 is an open-frame medical AC/DC power supply rated at 48 V, 1.25 A and 60 W. Its... Read more

$31.54 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    MEAN WELL RPS-60-48 is an open-frame medical AC/DC power supply rated at 48 V, 1.25 A and 60 W. Its 4 × 2-inch PCB format uses free-air convection cooling and Class I construction with protective grounding. Primary-to-secondary insulation is specified as 2 × MOPP; BF use requires appropriate consideration of the complete medical system. Continuous and short-duration output limits are given separately below.

    Product Datasheet

    Download MEAN WELL RPS-60 Datasheet (PDF)

    The RPS-60 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation.

    Model and Product Configuration

    Exact model RPS-60-48.
    Product type Open-frame, PCB-type medical AC/DC power supply with a single DC output and free-air convection cooling.
    System protection class Class I, with FG.
    Typical integration applications Medical computer monitors, oral irrigators, hemodialysis machines and sleep-apnea equipment, subject to the finished system’s safety assessment.

    Select by the complete model and the actual ratings below. The series number does not replace the model-specific continuous power rating.

    Model-Specific DC Output

    DC output voltage 48 V.
    Rated current 1.25 A.
    Printed current range 0–1.375 A; the part above rated current is subject to the short-duration peak rating.
    Rated output power 60 W, as printed for this exact model.
    Peak load 66 W for 10 seconds maximum, subject to the conditions below.
    Ripple and noise, maximum 100 mVp-p.
    Output-voltage adjustment 45.6–52.8 V.
    Voltage tolerance ±1.0%; includes set-up tolerance, line regulation and load regulation.
    Line regulation ±0.5%.
    Load regulation ±1.0%.
    Efficiency, typical 86%.

    The printed peak-load rating is 66 W for no more than 10 seconds. It is not a continuous rating. Peak duty cycle must not exceed 33% within every 30 seconds, and average output power must not exceed this model’s rated power. These limits apply together.

    Unless stated otherwise, parameters are measured at 230 VAC, rated load and 25°C ambient. Preserve the printed power and current limits together rather than increasing either limit through rounding.

    Ripple and noise are measured at 20 MHz bandwidth using a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors.

    Input, Timing and Leakage

    Input range 90–264 VAC or 127–370 VDC. Apply the input-voltage derating curve.
    AC frequency 47–63 Hz.
    Input current, typical 1.8 A at 115 VAC; 1 A at 230 VAC.
    Cold-start inrush, typical 30 A at 115 VAC; 60 A at 230 VAC.
    No-load power consumption Less than 0.75 W.
    Set-up and rise time 500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, full load.
    Hold-up time, typical 60 ms at 230 VAC; 12 ms at 115 VAC, full load.
    Leakage current Earth leakage less than 150 µA at 264 VAC; touch current less than 100 µA at 264 VAC. Touch current is measured from primary input to DC output.
    Block-diagram frequency 100 kHz switching-frequency reference.

    Protection

    Short circuit and overload Short-circuit protection is listed. Overload threshold: 115–150% of rated output power; hiccup mode recovers automatically after the fault is removed.
    Overvoltage threshold 55.2–64.8 V.
    Overvoltage recovery Output voltage shuts down; re-power on to recover.

    Protection thresholds are not extra continuous-output allowances. Apply the model-specific continuous and peak limits as well as temperature and input-voltage derating.

    Cooling, Derating and Environment

    Cooling and working ambient Free-air convection; −20 to +70°C with derating.
    Horizontal temperature/load curve 100% load from −20 to +50°C, reducing to 50% at +70°C.
    Input-voltage/load curve, 60 Hz 80% load at 90 VAC, rising to 100% at 115 VAC; 100% plateau through 264 VAC.
    Humidity and storage Working: 20–90% RH, non-condensing. Storage: −40 to +85°C and 10–95% RH, non-condensing.
    Temperature coefficient ±0.03%/°C over 0–50°C.
    Vibration 10–500 Hz, 2 G, 10 minutes per cycle; 60 minutes each along X, Y and Z.
    Operating altitude 3000 m maximum. Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless supply.

    Apply temperature and input-voltage limits together. Use the complete plotted curves for intermediate conditions; the upper operating temperature is a derated point, not a full-power rating.

    Dimensions, Installation and Connectors

    Dimensions, L × W × H 101.6 × 50.8 × 29 mm.
    PCB footprint and mounting holes 4 × 2 inches; four Ø3.3 mm holes on a 95.25 × 44.45 mm centre pattern, with 3.175 mm edge offsets.
    Drawing orientation and clearance Top-view connector numbering; dimensions in millimetres, general tolerance ±1 mm unless noted. The side view separately marks underside projections of 3 mm maximum; allow clearance according to the complete drawing.
    AC input connector CN1 JST B3P-VH or equivalent. Pin 1: AC/N; pin 2: no pin; pin 3: AC/L.
    DC output connector CN2 JST B4P-VH or equivalent. Pin 1: +V; Pin 2: +V; Pin 3: −V; Pin 4: −V.
    Mating connector references Housing: JST VHR or equivalent, as printed. Terminal: JST SVH-21T-P1.1 or equivalent. The VHR reference is a series name; select the exact housing position count and compatible terminal for CN1 or CN2.
    Board component references FS1 and FS2: T2.5/250V, as marked in the drawing. SVR1 is the output-voltage adjustment reference.
    Grounding and heatsinks Class I installation requires grounding. M1 is safety ground; for better EMC performance, establish an electrical connection between M1, M2 and chassis grounding. Do not short HS1 and HS2.

    The connector, housing and terminal references identify interface parts for selection; the catalogue does not state that loose mating housings, terminals, cables or mounting hardware are included. Select the compatible position count and wiring arrangement without inventing unprinted ordering suffixes. The duplicated +V or −V pins, where present, belong to the same single output. Use the complete mechanical drawing and installation instructions.

    Safety and EMC

    Medical safety standards listed as approved IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004.
    Isolation and BF application Primary-to-secondary isolation: 2 × MOPP. Suitable for BF applications with appropriate system consideration; this component does not by itself establish BF compliance of the complete medical equipment.
    Withstand voltage Input-to-output: 4 kVAC. Input-to-FG: 2 kVAC; output-to-FG: 1.5 kVAC.
    Insulation resistance Input-output, input-FG and output-FG: 100 MΩ at 500 VDC, 25°C and 70% RH.
    Additional insulation and IT approvals Primary-to-earth: 1 × MOPP; secondary-to-earth: 1 × MOPP. Approved IT standards listed: IEC62368-1:2014; UL62368-1, 2nd Ed; CSA C22.2 No.62368-1-14, 2nd Ed; TUV BS EN/EN62368-1:2014+A11.
    Emissions and system configuration BS EN/EN55011 (CISPR11) conducted and radiated emissions: Class B in Class I configuration. Harmonic current: BS EN/EN61000-3-2 Class A; voltage flicker: BS EN/EN61000-3-3.

    Immunity is specified to BS EN/EN55035 and BS EN/EN60601-1-2. BS EN/EN61000-4-2 ESD: level 4, 15 kV air and 8 kV contact; -4-3 RF: level 3, 10 V/m over 80 MHz–2.7 GHz, plus Table 9 fields of 9–28 V/m over 385 MHz–5.78 GHz.

    BS EN/EN61000-4-4 EFT: level 3, 2 kV; -4-5 surge: level 4, 4 kV line-to-FG and 2 kV line-to-line; -4-6 conducted susceptibility: level 3, 10 V; -4-8 magnetic immunity: level 4, 30 A/m. BS EN/EN61000-4-11: 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods.

    The catalogue EMC tests used the unit mounted on a 360 × 360 mm metal plate, 1 mm thick. Confirm EMC compliance again in the final assembled equipment.

    Weight, Reliability and Catalogue

    Single-unit catalogue weight 150 g (0.15 kg), explicitly stated in PACKING; this is a catalogue unit reference, not a measured shipping-parcel weight.
    Packing reference 96 pieces / 15.4 kg / 0.89 CUFT.
    Minimum MTBF estimates 5153.0 thousand hours by Telcordia SR-332 (Bellcore); 353.6 thousand hours by MIL-HDBK-217F at 25°C.
    Warranty and applicable version 3-year manufacturer warranty, subject to applicable terms. RPS-60-SPEC dated 2026-02-28; combined PDF pages 17–20.

    MTBF is a statistical reliability estimate, not a guaranteed service life.
