Description
5 "X3" package Basic functions Type: chassis type (modified) Output channel: CH3 Output voltage:-15V Output Current Rating (20.5CFM):0.95A Rated current range (20.5CFM):0.1 ~ 0.95A Output current range (natural air cooling):0.1 ~ 0.76A Output power rating 20.5CFM:135.8W Output rated power natural air cooling: 94.4W Input voltage: 90 ~ 264VAC,127 ~ 370VDC Size (mm):130X86X43
Product Features
1, 4 "x 2", 5 "x 3" general use small size.
2, Class I or Class II configuration, through the medical class safety certification (2xMOPP).
3. Built-in active PFC(RPT-160, MPQ-200), suitable for BF level application requirements.
4. Very low leakage current, built-in P.G and P.F signal output (RPT-160).
5. No-load power consumption <0.1W ~ 0.75W, protection type: short circuit/overload/overvoltage, over temperature (RPT-160).
6. 5V0.8A spare output (RPTG-160).
7. LED power on indicator (RPT-160/MPQ-200 only).
8, 3 years warranty.
