Description
5 "X3" package Output channel: CH2 Output voltage: 24V Output current: 0.1 ~ 2A Rated power: 73W Peak load (23.5CFM):95W Input voltage: 90 ~ 264VAC,127 ~ 370VDC Size (mm):127X76.2X31
Product Features
1, 4 "x 2", 5 "x 3" general use small size.
2, Class I or Class II configuration, through the medical class safety certification (2xMOPP).
3. Built-in active PFC(RPT-160, MPQ-200), suitable for BF level application requirements.
4. Very low leakage current, built-in P.G and P.F signal output (RPT-160).
5. No-load power consumption <0.1W ~ 0.75W, protection type: short circuit/overload/overvoltage, over temperature (RPT-160).
6. 5V0.8A spare output (RPTG-160).
7. LED power on indicator (RPT-160/MPQ-200 only).
8, 3 years warranty.
