MEAN WELL RQB Series: Wide Input Railway DC-DC Converter - RQB60W12-110S05

Description

Rated power: 60W Input Voltage (Range): Nominal 24V,36V,48V,72V,96V,110V(14~160V) Input current no-load: 15mA, full load: 610mA Single group output Output voltage: 5V Output current: 12A Efficiency (TYP.):89% Capacitive load (max):20000 μF Size (mm):57.9X36.8X12.7

Click to download Airtac product catalog

Product Features

1. The 1/4 brick (2.28 "x1.45" x0.5 ") conforms to the industrial standard pin, through the EN50155 railway standard.

2.12:1(14 ~ 160Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load, closed type.

3. Protection: short circuit (continuous)/overload/over temperature/over voltage/input under voltage, 3KVDC or 2KVAC input/output isolation.

4. Remote control on/off and remote sensing, fine-tuning output (± 10%),3-year warranty.

MEAN WELL RQB Series: Wide Input Railway DC-DC Converter - RQB60W12-110S05

Product form

Rated power: 60W Input Voltage (Range): Nominal 24V,36V,48V,72V,96V,110V(14~160V) Input current no-load: 15mA, full load: 610mA Single group output Output voltage:... Read more

$245.57 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Rated power: 60W Input Voltage (Range): Nominal 24V,36V,48V,72V,96V,110V(14~160V) Input current no-load: 15mA, full load: 610mA Single group output Output voltage: 5V Output current: 12A Efficiency (TYP.):89% Capacitive load (max):20000 μF Size (mm):57.9X36.8X12.7

    Click to download Airtac product catalog

    Product Features

    1. The 1/4 brick (2.28 "x1.45" x0.5 ") conforms to the industrial standard pin, through the EN50155 railway standard.

    2.12:1(14 ~ 160Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load, closed type.

    3. Protection: short circuit (continuous)/overload/over temperature/over voltage/input under voltage, 3KVDC or 2KVAC input/output isolation.

    4. Remote control on/off and remote sensing, fine-tuning output (± 10%),3-year warranty.
