MEAN WELL RSDW08 Series: DC-DC Converter - RSDW08F-03

Description

Series: Single group output Rated power: 8W Input voltage (range): standard voltage 24V(9~36V) Input current no-load: 10mA, full load: 344mA Output voltage: 3.3V Output current: 2000mA Efficiency (TYP.):80% Capacitive load (max):2000μF Size (mm):31.8X20.3X10.2

Click to download Airtac product catalog

Product Features

1. In line with EN50155 railway standards, DIP24 package, industry standard pins.

2.4:1 wide input range, operating temperature range -40~85 ℃, no minimum load required.

3. Closed type, protection: short circuit (continuous)/overload/overvoltage/input undervoltage, 1.5KVDC input/output isolation, remote on/off, 3-year warranty.

MEAN WELL RSDW08 Series: DC-DC Converter - RSDW08F-03

Product form

Series: Single group output Rated power: 8W Input voltage (range): standard voltage 24V(9~36V) Input current no-load: 10mA, full load: 344mA... Read more

$34.29 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Single group output Rated power: 8W Input voltage (range): standard voltage 24V(9~36V) Input current no-load: 10mA, full load: 344mA Output voltage: 3.3V Output current: 2000mA Efficiency (TYP.):80% Capacitive load (max):2000μF Size (mm):31.8X20.3X10.2

    Click to download Airtac product catalog

    Product Features

    1. In line with EN50155 railway standards, DIP24 package, industry standard pins.

    2.4:1 wide input range, operating temperature range -40~85 ℃, no minimum load required.

    3. Closed type, protection: short circuit (continuous)/overload/overvoltage/input undervoltage, 1.5KVDC input/output isolation, remote on/off, 3-year warranty.
