MEAN WELL RSDW10 Series: DC-DC Converter - RSDW10H-03

Description

Series: Single group output Rated power: 10W Input voltage (range): standard voltage 110V(43~160V) Input current no-load: 6mA, full load: 89mA Output voltage: 3.3V Output current: 2500mA Efficiency (TYP.):85% Capacitive load (maximum):2500μF Size (mm):31.8X20.3X12.7

Click to download Airtac product catalog

Product Features

1. In line with EN50155 railway standards, DIP24 package, industry standard pins.

2.4:1 wide input range, operating temperature range -40~85 ℃, no minimum load required.

3. Closed type, protection: short circuit (continuous)/overload/overvoltage/input undervoltage, 3KVDC input/output isolation, remote on/off, 3 years warranty.

MEAN WELL RSDW10 Series: DC-DC Converter - RSDW10H-03

Product form

Series: Single group output Rated power: 10W Input voltage (range): standard voltage 110V(43~160V) Input current no-load: 6mA, full load: 89mA... Read more

$45.00 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Single group output Rated power: 10W Input voltage (range): standard voltage 110V(43~160V) Input current no-load: 6mA, full load: 89mA Output voltage: 3.3V Output current: 2500mA Efficiency (TYP.):85% Capacitive load (maximum):2500μF Size (mm):31.8X20.3X12.7

    Click to download Airtac product catalog

    Product Features

    1. In line with EN50155 railway standards, DIP24 package, industry standard pins.

    2.4:1 wide input range, operating temperature range -40~85 ℃, no minimum load required.

    3. Closed type, protection: short circuit (continuous)/overload/overvoltage/input undervoltage, 3KVDC input/output isolation, remote on/off, 3 years warranty.
