Description
Series: Single group output Rated power: 40W Input voltage (range):Normal 24V(9~36V) Input current no-load: 15mA, full load: 1.6A Output voltage: 3.3V Output current: 10A Efficiency (TYP.):89% Capacitive load (maximum):26600μF Size (mm):50.8X25.4X10.5
Click to download Airtac product catalog
Product Features
Conform to EN50155 railway standards. DIP2 "x1" package, narrow face low height housing (10.5mm).
2, 4:1 wide input range, working temperature range -40 ~ +90 ℃, no minimum load, closed type.
3. Protection: short circuit (continuous)/overload/overvoltage/over temperature/input undervoltage, 1.6KVDC,3KVDC input/output isolation, remote on/off, 3-year warranty.
