MEAN WELL RSP-150-24 is a single-output enclosed AC/DC power supply rated at 24 V DC, 6.3 A and 151.2 W. It uses active PFC and free-air convection in a 30 mm-high enclosure; available load depends on input voltage and ambient temperature.
Product Datasheet
Download MEAN WELL RSP-150 Datasheet (PDF)
The RSP-150 section is on PDF pages 7, 8, 9. Refer to the complete mechanical drawings and notes when planning installation.
Model Code and Configuration
| Complete model |
RSP-150-24 |
| RSP |
Single-output enclosed AC/DC power supply series with active PFC |
| 150 |
Series output-power designation; this model is rated at 151.2 W |
| 24 |
Nominal DC output voltage: 24 V |
| Cooling |
Free-air convection |
| Enclosure profile |
30 mm height |
The printed model encoding defines series, power designation and output voltage. It does not define a separate remote-control option suffix for this model. Remote-control connector information is listed separately below.
Output Specifications
| Nominal DC output voltage |
24 V |
| Rated output current |
6.3 A |
| Output current range |
0 to 6.3 A |
| Rated output power |
151.2 W |
| Maximum ripple and noise |
150 mVp-p |
| Output voltage adjustment |
22.8 to 26.4 V |
| Voltage tolerance |
±1.0% |
| Line regulation |
±0.5% |
| Load regulation |
±0.5% |
| Typical efficiency |
89% |
Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient.
Ripple and noise: 20 MHz bandwidth; 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors.
Voltage tolerance includes setup tolerance, line regulation and load regulation.
Use the voltage-adjustment control shown in the mechanical drawing within the stated range. Adjustment does not authorize exceeding the listed current or power ratings.
Input and Timing
| AC input range |
85 to 264 VAC, universal full range |
| DC input range |
120 to 370 VDC |
| Input frequency |
47 to 63 Hz |
| Typical power factor at full load |
>0.93 at 230 VAC; >0.98 at 115 VAC |
| Typical AC input current |
1.6 A at 115 VAC; 0.8 A at 230 VAC |
| Typical cold-start inrush |
45 A at 230 VAC |
| Leakage current |
<2 mA at 240 VAC |
| Setup / rise time |
600 / 30 ms at full load |
| Typical hold-up time |
16 ms at full load |
| PFC / PWM switching frequency |
67 / 67 kHz |
The input-voltage derating graph is specified at 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC and remaining at 100% through 264 VAC. Apply this limit together with temperature derating; the full input range is not a full-power rating at every voltage.
Protection
| Listed protection functions |
Short circuit, overload, overvoltage and overtemperature |
| Overload threshold |
105% to 135% of rated output power |
| Overload response |
Constant-current limiting; automatic recovery after the fault condition is removed. |
| Overvoltage threshold |
26.4 to 32.4 V |
| Overvoltage recovery |
Output shutdown; reapply input power to recover. |
| Overtemperature recovery |
Output shutdown; automatic recovery after temperature decreases. |
The overload threshold is a protection characteristic, not a continuous overload or short-duration peak-power operating rating.
Operating Conditions and Derating
| Working ambient temperature |
-30 to 70 °C; apply model-specific derating |
| Cooling |
Free-air convection; horizontal mounting in the derating graph |
| Full-load temperature plateau |
Through 50°C under the applicable input conditions |
| High-temperature derating endpoint |
60% load at 70°C for this output-voltage group |
| Working humidity |
20% to 90% RH, non-condensing |
| Storage temperature / humidity |
-40 to +85°C; 10% to 95% RH, non-condensing |
| Temperature coefficient |
±0.05%/°C over 0 to 50°C |
| Vibration |
10 to 500 Hz; 2 G; 10 min/cycle; 60 min each along X, Y and Z axes. |
| Overvoltage category III |
Up to 2,000 m under EN61558, EN50178, EN60664-1 and EN62477-1 |
| Overvoltage category II |
Up to 5,000 m under UL/IEC/EN62368 |
| Maximum operating altitude listed |
5,000 m, subject to the applicable overvoltage category and altitude derating |
Follow the complete temperature curve between the stated plateau and endpoint. The working-temperature range does not mean full load at every temperature; do not extend the voltage-group curve beyond its plotted endpoint.
Above 2,000 m, reduce ambient-temperature limits by 3.5°C per additional 1,000 m for these fanless models.
Dimensions, Mounting and Terminal Wiring
| Housing dimensions, L × W × H |
199 × 99 × 30 mm |
| Mechanical case |
215A |
| Drawing tolerance |
±1 mm |
| Base mounting callout |
2-M4 L=4 mm |
| Side mounting callout |
4-M4 (both sides) L=4 mm |
| Width including projecting mounting tabs in the top view |
119 mm; distinct from the 99 mm housing width |
| Terminal 1 |
AC/L |
| Terminal 2 |
AC/N |
| Terminal 3 |
FG (protective earth) |
| Terminal 4 |
DC OUTPUT -V |
| Terminal 5 |
DC OUTPUT -V |
| Terminal 6 |
DC OUTPUT +V |
| Terminal 7 |
DC OUTPUT +V |
Use the complete mechanical drawing for hole positions and clearances. Mounting callouts are not quantities of included screws. L=4 mm is the printed thread-depth callout; these pages do not specify tightening torque or wire gauge.
FG is protective earth. Observe the separately assigned AC input and DC output terminals; repeated -V or +V terminals belong to the same single output.
Remote Control and Optional Connector Information
| Remote-control function |
The datasheet feature list states built-in remote ON-OFF control |
| CN1 power ON level |
0 to 0.8 VDC |
| CN1 power OFF level |
4 to 10 VDC |
| CN1 pin 1 |
RC+ |
| CN1 pin 2 |
RC- |
| CN1 header designation as printed |
JST B-XH or equivalent |
| Mating housing designation as printed |
JST XHP or equivalent |
| Contact-terminal designation as printed |
JST SXH-001T or equivalent |
The mechanical drawing marks the remote-control connector as optional. Confirm the actual connector provision before wiring; do not assume that a mating housing, crimp terminals or a cable assembly is included.
The connector names above are transcribed as printed. These pages do not provide any additional pole-count suffix, exact supplied quantity, open-circuit default, permitted control current or maximum cable length. Do not complete abbreviated part numbers by borrowing codes from another series.
No separate dedicated bracket, terminal-cover or cable-kit order code is specified in these pages. Use only separately verified compatible accessories; the mounting drawing alone does not establish their supply or compatibility.
Safety, EMC and Reliability
| Safety approvals listed for this model |
UL62368-1; TUV BS EN/EN62368-1; BS EN/EN61558-1; BS EN/EN61558-2-16; EAC TP TC 004; CCC GB4943.1; BSMI CNS15598-1; AS/NZS 62368.1; IS13252 (Part 1) / IEC60950-1 |
| Withstand voltage |
I/P-O/P: 4 kVAC; I/P-FG: 2 kVAC; O/P-FG: 0.5 kVAC |
| Insulation resistance |
100 MΩ at 500 VDC / 25°C / 70% RH for I/P-O/P, I/P-FG and O/P-FG. |
| EMC emission, datasheet statement |
BS EN/EN55032 (CISPR32) Class B; BS EN/EN61000-3-2 and -3; EAC TP TC 020; CNS15936 Class B; GB9254 Class B; GB17625.1. |
| EMC immunity, datasheet statement |
BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN55035, light-industry level; EAC TP TC 020. |
| Minimum MTBF, Telcordia SR-332 (Bellcore) |
2253.9 thousand hours |
| Minimum MTBF, MIL-HDBK-217F at 25°C |
290.7 thousand hours |
The power supply is a component for installation in final equipment. EMC compliance must be reconfirmed on the completed equipment.
The listed approvals and standards apply to this model and datasheet revision. They do not establish compliance of an entire installation. MTBF figures are reliability-model results, not guaranteed service life or warranty duration.
Catalog Weight and Product Features
| Per-unit catalog PACKING reference |
600 g (0.6 kg) |
| Carton packing reference |
24 units / 15.4 kg / 0.89 CUFT |
| Power indicator |
LED power-on indicator |
| Application examples |
Factory automation, test and measurement, laser-related machines, burn-in facilities and RF equipment |
The per-unit figure is the catalog PACKING reference, not a measured net mass or a customer parcel weight. Carton totals must not be used as the single-product weight.
The manufacturer datasheet lists a 3-year warranty; coverage is governed by the applicable manufacturer warranty terms.
Datasheet Scope
| Series section |
Combined RSP catalog, PDF pages 7, 8, 9 |
| Model specification page |
8 |
| Mechanical and curve page |
9 |
| Specification revision |
2025-09-22 |
Refer to the linked manufacturer PDF for the complete mechanical drawing, connector information and derating curves before installation.
